LK-30A
PRODUCT DETAIL
MACHINE FEATURES
Moving table by slider for drilling
and tapping.
Main construction of milling
mechanism; upward and downward, backward and forward can be moved easily. To
calibrate the tooling and mold is easy.
Mold can be changed easily, material
loading and unloading is easy.
Type of clamp: Hydraulic vice or
hydraulic chuck…..etc.
MACHINE SPECIFICATION
|
MODEL |
LK-30A (2 Spindle) |
|
Spindle Taper |
MT-4 |
|
Spindle Speed |
200-2000 r.p.m. |
|
Spindle Travel |
145 mm |
|
Work Table Travel |
250 mm |
|
Cross Travel |
150 mm |
|
Vertical Travel |
500 mm |
|
Main Spindle Power |
3HP or Optional |
|
Both Spindle Distance |
250 mm |
|
T-Slots |
16 mm x 3 Slots |
|
Working Table |
230 mm x 770 mm |
|
Net Weight |
950 kgs |
|
Max. Tapping Capacity |
30 mm |
