LK-32, LK-32L
PRODUCT DETAIL
MACHINE FEATURES
Appeal to automate planning,
allowing users to select the desired the FEEDER share with users choose whether
with this function according to its own operating needs.
MACHINE SPECIFICATION
|
MODEL |
LK-32 |
LK-32L |
|
Max. Turning Diameter |
220 mm |
350 mm |
|
Max Turning Length |
130 mm |
580 mm |
|
Swing Over Bed |
300 mm |
650 mm |
|
X Axis Travel |
300 mm |
200 mm |
|
Z Axis Travel |
150 mm |
580 mm |
|
Spindle Chuck Dia. |
8” |
10” |
|
Spindle Speed |
3000 r.p.m. |
3000 r.p.m. |
|
Spindle Motor |
7.5/HP |
10/HP |
|
Spindle Bore |
52 |
52 |
|
Turret Number of Tools |
8 |
8 |
|
Coolant Pump Motor |
1HP 2P |
1HP 4P |
|
Floor Space |
1750 x 1300 x 1800 mm |
1870 x 1650 x 1750 mm |
